BARiT® Design Floors

BARiT® Design Floors

Meet our award-winning floor - the BARiT® museum terrazzo

MASTERTERRAZZO®

The epoxy resin-bound BARiT MASTERTERRAZZO® combines classic terrazzo highlights with varied colours and aggregates at a very low construction height. Sharp and round theralite aggregates in natural colours give the floor a modern classic terrazzo look.

Design is paramount for MASTERTERRAZZO®. The customer determines the colouring of the base grain and additionally the size, quality and quantity of aggregates.

Quick Info

  • seamless
  • aesthetic
  • slip-resistant in accordance with BGR 181 R 9
  • chemical and mechanical stability
  • suitable for wheelchairs
  • easy to clean and disinfect
  • fire classification Bfl-s1
  • Low emissions according to AGBB

Optic

The basic granules of the MASTERTERRAZZO® can be selected according to RAL colours. In addition, BARiT offers a large spectrum for Terralith gravel: Crystal white, creek stone, amber or coal black gravel create a living terrazzo effect. Pastel coloured terrazzos in pearl white, light ivory, light gray or platinum gravel combined with precious white crystal or natural gray slate granules give a classic terrazzo look. Coloured granules such as fresh green tones emphasize an individually designed terrazzo. Specialized granules are available based on a selection of RAL colours for areas over 200m².

Samples

Traffic white - terralith 1
Traffic white - terralith 1
Traffic white - terralith 5
Traffic white - terralith 5
graphiteblack - terralith
graphiteblack - terralith

Properties

MASTERTERRAZZO® consists of water-clear epoxy resin and polyurethane coated colorfast granules, which are combined with Terralith granules. The supplemental granules can be up to 2.5 mm in size, sharp-edged or rounded. The coating can be installed in a layer 8 - 10 mm thickness. It can be installed on top of calcium-sulfate based false and subflooring, cement as well as anhydrite flooring, and especially on heated flooring. This covering is installed without any joints or edges, eliminating any hazards for tripping.

MASTERTERRAZZO®, due to its load-bearing capacity, is ideal for high traffic areas and due to its seamless surface remains abrasion-free even with permanent exposure. With its seamless surface MASTERTERRAZZO® is easy to clean, disinfect and maintain, thus providing hygienic protection.

Datasheet
Fillers Granulates
Chemical resistance to resistance list and self test
Light-Temperature resistance 100 °C temporarily / -30 °C to +70 °C consistently
Working under conditions of:
  • ground temperature max.
  • ground temperature min.
  • air humidity
  • residual moisture of the ground
  • 22 °C
  • 18 °C
  • 40 - 85%
  • < 3 %
Solid matters 100 %
Flash point > 100 °C
Grain BARiT card of grains
Fire behaviour DIN EN 13501-1 Bfl-s1, hardly inflammable
Consumption/m² 2 kg/mm
Bending tensile strength DIN 1164** > 10 N/mm²
Grade of gloss silk gloss or mat
Compression strength DIN 1164** > 40 N/mm²
Adhesive pull strength DIN EN 24624 > 1 N/mm²
Light-fastness conditionally resisting to UV
Cleaning BARiT Cleaner*
Binding agent EP-resin
Curing time at 20°C:
  • mechanical stability
  • not sticky
  • walking admissible
  • final hardness
  • after 7 days fully capable of bearing
  • after 12 hours
  • after 16 hours
  • after 7 days
