VITMOLIT
4-1 = The new lightweight and rapid compensations by BARiT connect the four main properties of floor construction: light weight, fast readiness, inert insulation and simple installation.
Vitmolit and Vitmopox are ideal as super fast levelling layers between wooden and brick coffered ceilings, vaulted and concrete in new ceilings in new builds and renovations.
Both levelling layers serve as subfloors in static, temporal, impact noise and thermal insulation requirements.
Quick Info
- planar
- low weight
- fast readiness
- different height compensation
- thermal conductivity of λ = 0.19 W / mK
- good compaction and
- simple to use
- recyclable
Optic
Properties
VITMOLIT consists of recyclable, lightweight granules, which are bound together with a special, quick-setting cement. Due to its material properties, Vitmolit is free of shrinkage and bonds as a levelling layer with an inert thermal insulation and compression strength of 10 N / mm 2. Structural processing is done in the same way as for standard, conventionally produced cement flooring.
Vitmolit und Vitmopox are installed with layer thicknesses from a minimum of 15 mm to a maximum of 50 mm. Thicker layers up to 350 mm can be achieved with multiply applied layers. This leveling layer is accessible after only a few hours. After twelve hours the levelling layer is set and ready for installation of ceramic coatings, textile coatings, natural stone, PVC floorings, rubber of linoleum.
Datasheet| Suitability | super-light and heat insulation layer |
| Basic raw-material | inflated glas |
| Binding agent | special cement |
| Application thickness | ab 15 - 50 mm |
| Fillers/pigments | Additives |
| Technical properties | Water-mineral binding to DIN EN 13 813 |
| Own weight | less than < 700 kg/m³ |
| Resistance to pressure DIN 1164** | ca. 10 N/mm² |
| Heat insolation according to (Z-23-11-1154) | K-Wert = 0,08 W/mk, λ = 0,19 |
| Processing | easy mixing and pumping, manual and mechanical densifying and smoothing only for permanently dry floor subconstructions |
| Environmental compatibility | free from harmful substances and poison, full recyclability |
| Use | Indoor |
Curing at 20°C
|
|
| Fields of use | Remodeling new buildings |
